HG5000-5G4AX
3000 Mbps | WiFi 6 | OFDMA Multi-User | One SSID for Dual Band
5×GE + 4×4 WiFi 6(2+2 802.11AX) + USB3.0
1024-QAM and larger 160MHz band width(2402Mbps on 5GHz band and 574Mbps on 2.4GHz band), greatly improve network efficiency!
MU-MIMO allows multiple terminals to share the channel at the same time, achieves up to 4x capacity.
Target Wake-up Technology can effectively reduce the power consumption
of your device to extend the life of the device.
|
○ Hardware Parameter |
|
|
Dimension |
115*115*180mm(L×W×H) |
|
Net weight |
0.56Kg |
|
Working condition |
Operating temp: 0 ~ +50°C Operating humidity: 5 ~ 90% (non-condensed) |
|
Storing condition |
Storing temp: -30 ~ +60°C Storing humidity: 5 ~ 90% (non-condensed) |
|
Power adapter |
DC 12V,1.5A |
|
Power supply |
≤18W |
|
Interface |
5×GE + 4×4 WiFi6 + USB3.0 |
|
Indicators |
POWER / STATUS / NETWORK / RJ45 |
|
Button |
Reset, WPS |
|
|
|
|
○ Interface parameter |
|
|
User Interface |
5×10/100/1000Mbps auto adaptive Ethernet interface , RJ45 connectors(1×WAN, 4×LAN) |
|
WLAN Interface |
l Compliant with IEEE802.11b/g/n/ac/ax l 2402 Mbps on 5GHz and 574Mbps on 2.4 GHz l Support 4×4 MIMO, 5dBi internal antenna l 128 connected device |
|
USB |
1×USB 3.0 for Shared Storage/Printer |
|
○ Function Data |
|
|
Management |
WEB/Telnet |
|
Multicast |
l Support IGMP v1/v2/v3 l Support IGMP Proxy and MLD Proxy l Support IGMP Snooping and MLD Snooping |
|
WAN |
Supports any internet service up to 1Gbps |
|
Wireless |
l WiFi6: 802.11a/n/ac/ax 5GHz & 802.11g/b/n/ax 2.4GHz l WiFi Encryption:WEP-64/WEP-128/ WPA/WPA2/WPA3 l Support OFDMA, MU-MIMO, 1024-QAM l Smart Connect for one WiFi name - One SSID for 2.4GHz and 5GHz dual band |
|
L3 / L4 |
l Support IPv4, IPv6 and IPv4/IPv6 dual stack l Support DHCP/PPPOE/Statics l Support Static route,NAT l Support DMZ, DNS, ALG,UPnP l Support Virtual Server l Support NTP (Network Time Protocol) |
|
DHCP |
Support DHCP Server & DHCP Relay |
|
Security |
l Support Mac filter based on MAC or URL l Support ACL l Guest Wi-Fi access and Parent Control l Fast Encryption – One-touch WPA wireless security encryption with the WPS button l Anti-DDOS, Firewall |
