Dual-band concurrent operation at 2.4GHz and 5GHz with combined throughput of 1.2Gbps(300Mbps at 2.4GHz and 867Mbps at 5GHz). Take advantage of dual bands to improve users' online experience!
Strong signals extend throughout your house! There are multiple connection channels between any two nodes and all nodes are connected to form a whole network to achieve higher throughput.
PA: Improve wireless signal transmission to bring a stronger coverage
LNA: Reduce wireless interference to bring a stable signal
Maximum connection devices up to 128 !
Set up EasyMesh WiFi
Gigabit port, ultra-performance mesh wiFi network cover every inch of your home in super-fast and seamless WiFi connectivity room to room, wall to wall, floor to floor.
Product Specifications Overview
|
○ Hardware Parameter |
|
|
Dimension |
115mm ×115mm ×180m(L×W×H) |
|
Net weight |
560g |
|
Operating condition |
Operating temp: 0 ~ +55°C Operating humidity: 10 ~ 90% (non-condensed) |
|
Storing condition |
Storing temp: -30 ~ +60°C Storing humidity: 10 ~ 90% (non-condensed) |
|
Power adapter |
DC 12V,1A, external AC-DC power adaptor |
|
Power supply |
≤ 10W |
|
Interface |
1GE+1FE+WiFi5 |
|
Indicators |
3, For Status of SYS,LAN1,LAN2 |
|
|
|
|
○ Interface parameter |
|
|
LAN Interface |
1*10/100Mbps and 1*10/100/1000Mbps auto adaptive WAN/LAN Ethernet interface , RJ45 connectors |
|
WLAN interface |
Compliant with IEEE802.11b/g/n/ac l 2.4GHz Operating frequency: 2.400-2.483GHz l 5GHz Operating frequency: 5.150-5.825GHz WiFi: l MIMO 2×2 For 2.4GHz,MIMO 2×2 For 5GHz, l 4×5dBi external antenna, rate up to 1.166Gbps, Multiple SSID l TX power: 11n--22dBm / 11ac--24dBm |
|
WPS Button |
Quickly pair two EasyMesh WiFi routers with the WPS button |
|
○ Function Data |
|
|
Management |
Web |
|
Data Service |
l Full speed non-blocking switching l 2K MAC address table l Integrated port monitoring, port mirroring, port rate limiting, port SLA, etc l Support auto polarity detection of Ethernet ports (AUTO MDIX) l Integrated IEEE802.1p QoS with four level priority queues l Support IGMP v1/v2/v3 snooping/proxy and MLD v1/v2 snooping/proxy l Support bridge, router and bridge/router mixed mode |
|
Wireless |
l Support Wireless AP mode l Support 802.11 b/g/n/ac l Support Multiple SSID l Authentication : WEP / WAP-PSK(TKIP) / WAP2-PSK(AES) l Modulation type: DSSS, CCK and OFDM l Encoding scheme: BPSK, QPSK, 16QAM and 64QAM l Support EasyMesh protocol |
|
WAN/LAN |
PPPoE, DHCP Client, Static IP |
