4G CPE Smart Router Manufacturers and Suppliers - SmileMbb

LTE Cat4 CPE

Item No.: XMC1841E
XMC1841E LTE CPE is developed based on several worldwide proven chipset solutions, integrated with the high technologies in LTE CAT4, WIFI  Hotspot, Ethernet LAN, and Web-UI management.
  • ChipsetASR1803s+ASR5803W
  • Description Parameters Review
    Description

    XMC1841E | SmileMbb 4G CPE Smart Router

    4G LTE CAT4| 150Mbps High-Speed | Cost-Effective

    High Performance & Cost-Effective Chipset

    Outstanding Performance as Always

    Minimalist Hardware Design

    Plug & Play

    Plug in the SIM card and connect your devices. Where there is a signal, there is WIFI.

    Parameters

     Technical Parameter

    Chip Platform

    ASR1803s+ASR5803W

    Frequent Band

    XMC1841E-EU:

    FDD LTE: B1/B3/B5/B7/B8/B20/B28

    TDD LTE: B38/B40/B41

    UMTS: B1/B5/B8

    XMC1841E-AU:

    LTE-FDD: B1\B2\B3\B4\B5\B7\B8\B28\B66

    LTE-TDD: B40

    WCDMA: B1\B2\B4\B5\B8

    Protocol Version

    4G: 3GPP R9 Cat4 + 3G: 3GPP R7

    Data Rate

    FDDDL/UL up to 150Mbps/50Mbps

    TDD DL/UL up to 110Mbps/10Mbps

    3G:  DL/UL up to 21Mbps/5.76Mbps

    WiFi Standard

    802.11 b/g/n, 1*antenna, 72.2Mbps

    Size

    150×105×30mm(L×W×H)

    Weight

    230g

    Power Supply

    DC 12V,1A

    Physical Interface

    1*RJ45(100M, 1 LAN)1*4FF USIM, 1*DC Input Port

    LED

    POWER, WiFi, LAN, DATA,  LTE

    Button

    Reset/WPS

    Characteristics

    Firewall: Filtering/ Port Mapping

    Local & Remote management
